TD SERIES
技术参数
|
型号Model |
TD400 | TD600 | TD800 | TD1000 | TD1300 | TD1500 | TD1800 |
|
立体声输出功率 8Ω Stereo Power |
400Wx2 |
600Wx2 |
800Wx2 |
1000Wx2 |
1300Wx2 |
1500Wx2 |
1800Wx2 |
|
立体声输出功率 4Ω Stereo Power |
600WWx2 |
900Wx2 |
1200Wx2 |
1500Wx2 |
2000Wx2 |
2200Wx2 |
2700Wx2 |
|
桥接输出功率 8Ω Bridged mono output |
1200W |
1800W |
2400W |
3000W |
3900W |
4400W |
5400W |
|
信噪比S/N Ratio |
105dB |
105dB |
105dB |
105dB |
110dB |
110dB |
110dB |
|
转换速率 Conversion Rate |
50v/μS |
50v/μS |
60v/μS |
60v/μS |
70v/μS |
70v/μS |
70v/μS |
|
阻尼系数 Damping Factor |
500:1 |
500:1 |
550:1 |
550:1 |
600:1 |
600:1 |
600:1 |
|
频率响应Frequency Response |
20Hz-20KHz(+/-0.5dB) |
||||||
|
总谐波失真THD |
≤0.03%Rated Power@8Ω 1KHZ |
||||||
|
互调失真IMD |
≤0.01%Rated Power@8Ω |
||||||
|
输入灵敏度 Input Sensitvity |
0.775v. 1.0v. 1.44v |
||||||
|
输入阻抗 Input Impedance |
20KΩ(Balance)/10KΩ(Unbalance) |
||||||
|
串音Crosstalk |
≤-80dB | ||||||
|
保护功能protection |
直流，短路，超温，压限，软启动等DC,Short circuil,Temperature,Clip,Limiter,Slow start |
||||||
|
重量Weight |
12kg |
12kg |
12.5kg |
12.5kg |
13kg |
13kg |
14kg |
|
尺寸Dimensions(WxDxH) |
483x381x89mm |
||||||
