MT-6
Product Description
1. The box body adopts high-quality plywood combined with slotting and wedging technology to make the trapezoid box structure more solid and durable.
2. The tweeter driver is made of 1.35 "Malaysia imported diaphragm assembly, the horn can be rotated at multiple angles, and the bass 6.5" is also made of Malaysia imported materials. The mid frequency voice is full and thick, with high reducibility.
3. The well-designed and rapid expansion of the high-frequency horn adjusts the time difference between the high-frequency and low-frequency units and corrects the phase angle difference, and ensures the smooth wavefront, provides accurate beam pattern control and eliminates the interference near the frequency division point.
4. The frequency division network adopts black polypropylene high-quality capacitor and circular air core inductor, and the treble adopts Bost patent protection circuit design.
5. Through many years of sound concept design by senior engineers, the trapezoid box structure is firm, and the horizontal and vertical cranes are very flexible and convenient.
2. The tweeter driver is made of 1.35 "Malaysia imported diaphragm assembly, the horn can be rotated at multiple angles, and the bass 6.5" is also made of Malaysia imported materials. The mid frequency voice is full and thick, with high reducibility.
3. The well-designed and rapid expansion of the high-frequency horn adjusts the time difference between the high-frequency and low-frequency units and corrects the phase angle difference, and ensures the smooth wavefront, provides accurate beam pattern control and eliminates the interference near the frequency division point.
4. The frequency division network adopts black polypropylene high-quality capacitor and circular air core inductor, and the treble adopts Bost patent protection circuit design.
5. Through many years of sound concept design by senior engineers, the trapezoid box structure is firm, and the horizontal and vertical cranes are very flexible and convenient.
Applications
Application Range: Conference room, lecture hall, multi-function hall, auditorium, school, coffee shop, station, wharf
Product Features
Specifications
|
Drivers |
LF: 1*6.5" / HF: 1*1.35" |
|
Rated Power |
150W |
|
Rated power |
300W |
|
Nominal impedance |
8 ohms |
|
Frequency Range |
90Hz-20KHz |
|
Sensitivity(1m/1W) |
95dB |
|
MAX SPL |
120dB |
|
Dispersion(HxV) |
90° *60° |
|
Construction |
|
|
Enclosure Material |
plywood |
|
Enclosure Grille |
Black round hole dustproof steel mesh with breathable cotton inside |
|
Finish |
Black environment-friendly waterproof and wear-resistant paint (color can be customized according to customer requirements) |
|
Dimensions(W*D*H)（mm) |
254*235*400 |
|
Net weight) (Kg |
8.5Kg |
Configuration
