Products
LAV8
Product Description
Applications
Application range: concert, conference hall, lecture hall, multi-function hall, auditorium, schools, etc.
Specifications
|
Drivers |
LF: 2*10"Neodymium magnet /MF：1*8"Neodymium magnet/ HF: 2*2.55" Neodymium magnet |
|
Rated Power |
800W |
|
Rated power |
1000W |
|
Nominal impedance |
8 ohms |
|
Frequency Range |
67Hz-19KHz |
|
Sensitivity(1m/1W) |
106dB |
|
MAX SPL |
138dB |
|
Dispersion(HxV) |
90°*14° |
|
Construction |
|
|
Enclosure Material |
Birch Plywood |
|
Enclosure Grille |
Air permeable cotton in black round hole dustproof steel mesh |
|
Finish |
Black environmental protection imported polyurea wear-resistant paint (customized color according to customer requirements) |
|
Dimensions(W*D*H)（mm) |
W700*D460*H310 |
|
Net weight (Kg) |
34Kg |
Configuration
