FC115M(15 "two frequency speakers）
Product Description
1. The cabinet is made of high quality plywood with into the slot is woven process, make the structure more durable, reduce dyeing.
2. High drive adopts 3 "Europe imported diaphragm components, 15" bass unit adopts imported materials in Malaysia. With super sound pressure level and clear and transparent in high frequency, whether singing or doing high-end business meeting amplification of a class is the best choice.
3. The crossover network USES the aluminum shell resistance of polypropylene capacitors and super cooling, cooperate with the aluminum radiator, maximize the efficiency and reduce the unnecessary distortion.
4. After a lot of experiments on simulation and optimization design meticulously, high-pitched adopted BOST company patent protection circuit, ensure do not produce frequency drift when he worked in high power, high and low sounds perfect cohesion, low-frequency vigorous powerful, flexible, intermediate frequency bright transparent, voices and luxuriant, easily into the microphones.
2. High drive adopts 3 "Europe imported diaphragm components, 15" bass unit adopts imported materials in Malaysia. With super sound pressure level and clear and transparent in high frequency, whether singing or doing high-end business meeting amplification of a class is the best choice.
3. The crossover network USES the aluminum shell resistance of polypropylene capacitors and super cooling, cooperate with the aluminum radiator, maximize the efficiency and reduce the unnecessary distortion.
4. After a lot of experiments on simulation and optimization design meticulously, high-pitched adopted BOST company patent protection circuit, ensure do not produce frequency drift when he worked in high power, high and low sounds perfect cohesion, low-frequency vigorous powerful, flexible, intermediate frequency bright transparent, voices and luxuriant, easily into the microphones.
Applications
Application Range: Return to the stage, conference rooms, lecture hall, multi-function hall, auditorium, school, etc
Product Features
Specifications
| Model | FC115M |
|
Drivers |
LF: 1*15" / HF: 1*3" |
|
Rated Power |
550W |
|
Rated power |
800W |
|
Nominal impedance |
8 ohms |
|
Frequency Range |
35Hz-19KHz |
|
Sensitivity(1m/1W) |
99dB |
|
MAX SPL) |
129dB |
|
Dispersion(HxV) |
90°*60° |
|
Construction |
|
|
Enclosure Material |
Birch plywood |
|
Enclosure Grille |
Black hole dustproof steel stick breathable cotton in the grid |
|
Finish |
Dark green water resistant paint (color can be customized) |
|
Dimensions(W*D*H)（mm) |
W478*D368*H690 |
|
Net weight (Kg) |
28.5Kg |
Configuration
